Manual Chain Link Machine
Heavy-duty cast iron body. Simple winding rod assembly. Manually operated or with 1 HP motor attachment. Zero complex electrical circuits. Perfect for rural startups.
ISO 9001:2015
CE Certified
Manual Chain Link Machine
Rs. 60,000 + 18% GST
+ 18% GST | FOB Pune
250–300 kg/8h
Output Rate
1.5–4 mm
Wire Range
10 ft max
Weave Width
Heavy-duty cast iron body. Simple winding rod assembly. Manually operated or with 1 HP motor attachment. Zero complex electrical circuits. Perfect for rural startups.
Prakash Industries machines are built to handle continuous industrial environments. Designed by engineering professionals with premium alloys and electronic controllers to ensure maximum uptime, speed, and safety on the production floor.
- Premium grade materials with heavy-duty cast iron panels
- Highly optimized power efficiency configurations
- Comprehensive 1-year manufacturing warranty
- Designed for cottage, startup, or larger perimeter mesh manufacturing
| Model Name | Manual Chain Link Machine |
| Category | Manual Series |
| Daily Output | 250–300 kg/8h |
| Wire Range | 1.5–4 mm |
| Width | 10 ft max |
| Manufacturer | Prakash Industries |
| Warranty | 12 Months (Manufacturing defects) |
| Location of Origin | Pune, Maharashtra, India |
- Heavy-duty cast iron main housing for maximum durability
- Manual winding mechanism requiring no complex electronics
- Easy attachment option for a 1 HP electric motor
- Perfect for rural areas and low-budget startups
- Extremely low operating and maintenance overheads
- Easy hand-cranked width sizing adjustment
- Compatible with multiple wire thicknesses up to 4.0 mm
- On-site machine installation and operator training
Prakash Industries — Machine Brochure
About This Machine
Overview: The Manual Chain Link Machine is a fully manually operated or motor-assisted winding rod machine designed as a highly reliable, low-cost entry-level machine.
Working Process: The operator turns the manual crank handle (or uses the motor foot switch) to rotate the flat winding blade inside the tube, forming individual wire spirals which are manually interlocked together.
Manufacturing Quality: Crafted with durable cast iron blocks and high-tensile alloy blades. Manufactured and assembly-verified at Pune, India.
Industries Used
Cottage industries, small rural workshops, startup businesses, and local wire netting dealers.
Key Advantages
Affordable startup cost, simple cast-iron build, zero complex circuits, and can run without a three-phase power grid (optional 1 HP motor).
Quality & Standards
Traditional mechanical tolerances, heavy cast-iron build mass for wear protection, and manual leverage control.
Support Included
Includes complete on-site installation, 12 months mechanical warranty, and 2 days hands-on operator training.
Machine Video Demonstration
Watch this high-capacity chain link fence weaving machine in action, showing continuous automatic feeding, twisting, and knuckling.
Frequently Asked Questions
What raw materials are required for this machine?
This machine is fully compatible with Hot-Dip Galvanized (GI) wire, PVC-Coated wire, and Mild Steel (MS) black wire.
Is on-site installation and training included?
Yes! We provide on-site machine commissioning, test run validation, and hands-on operator training for 2 days at your site.
What is the power grid requirement?
Most automatic models require a 415V Three-Phase electrical grid layout. Manual and small semi-automatic machines can be configured for 220V Single-Phase supplies.
